Asbestos Air Testing and Monitoring Explained
Important Testing Information
Asbestos air testing should only be performed by qualified professionals with appropriate accreditation. The information in this article explains the procedures but does not qualify readers to conduct testing themselves.
Content coming soon
The Air Testing Process
1. Sample Collection
A calibrated air pump draws a measured volume of air through a filter at a constant flow rate. The pump and filter are positioned at breathing height (approximately 1.5m from the floor) to capture representative samples. The sampling duration and flow rate vary depending on the type of test.
2. Filter Preparation
After sampling, the filter is prepared for analysis using the membrane filter method. This process makes the filter transparent, allowing for microscopic examination. This involves acetone vapor treatment and mounting the filter on a microscope slide using triacetin.
3. Fiber Counting
Using phase contrast microscopy (PCM), an analyst examines multiple fields of view on the prepared slide, counting fibers that meet specific dimensional criteria (longer than 5μm, width less than 3μm, and aspect ratio greater than 3:1). PCM cannot distinguish between asbestos and non-asbestos fibers.
4. Calculation of Results
The fiber concentration is calculated by dividing the number of fibers counted by the volume of air sampled, typically expressed in fibers per milliliter of air (f/ml). This result is then compared to relevant control limits to assess compliance.
Types of Asbestos Air Testing
There are several types of asbestos air testing, each serving a specific purpose in asbestos management:
1. Background Air Monitoring
Purpose:
Establishes the normal airborne fiber levels before any asbestos work begins.
When Used:
- Before commencement of asbestos removal projects
- When there are concerns about possible fiber release from deteriorating materials
- To establish a baseline for comparison with subsequent tests
Typical Results:
Normal background concentrations in buildings are typically below 0.01 f/ml (fibers per milliliter).
2. Leak Testing (Control Monitoring)
Purpose:
Monitors areas outside asbestos enclosures during removal work to check for potential fiber release.
When Used:
- During licensed asbestos removal work
- In areas adjacent to enclosures, especially where people may be present
- Near airlocks, waste routes, and negative pressure units
Control Limit:
Fiber levels should not exceed 0.01 f/ml. Any higher reading suggests a breach in the enclosure that requires immediate action.
3. Personal Monitoring
Purpose:
Measures individual workers' exposure to airborne asbestos fibers during specific activities.
When Used:
- During asbestos removal or disturbance activities
- For workers inside enclosures
- During non-licensed asbestos work
- For exposure risk assessment and respiratory protection selection
Control Limits:
- Control limit: 0.1 f/ml averaged over a 4-hour period
- Short-term exposure limit: 0.6 f/ml averaged over a 10-minute period
4. Clearance Testing (4-Stage Clearance)
Purpose:
Verifies that an area is safe for reoccupation following asbestos removal work.
The 4 Stages:
- Stage 1 - Preliminary check: Ensures work has been completed, the area is free of visible debris, and the enclosure is intact
- Stage 2 - Thorough visual inspection: Detailed examination to ensure all ACMs have been removed and the area is clean
- Stage 3 - Air monitoring: Air testing inside the enclosure under disturbed conditions
- Stage 4 - Final assessment: Inspection after enclosure dismantling to confirm the area is suitable for reoccupation
Clearance Indicator:
Air test results must be below 0.01 f/ml to pass clearance. The analyst will issue a certificate of reoccupation upon successful completion.
5. Reassurance Monitoring
Purpose:
Provides confidence that airborne fiber levels remain at acceptable levels after asbestos work or when there are concerns about possible fiber release.
When Used:
- After completion of asbestos removal projects
- Following accidental disturbance of asbestos materials
- When there are concerns about deteriorating asbestos-containing materials
- As part of ongoing asbestos management plans
Typical Results:
Results should be below 0.01 f/ml, comparable to normal background levels.
Understanding Air Test Results
Interpreting air test results requires knowledge of the relevant control limits and clearance indicators:
| Fiber Concentration | Interpretation | Action Required |
|---|---|---|
| < 0.01 f/ml | Below clearance indicator | None - area is safe for normal occupancy |
| 0.01 - 0.1 f/ml | Above clearance indicator but below control limit | Further cleaning and retesting required for clearance purposes. Investigate source if from reassurance or leak testing. |
| > 0.1 f/ml | Above control limit | Immediate action required. RPE necessary. Potential breach of regulations. |
It's important to note that PCM cannot distinguish between asbestos and non-asbestos fibers. In environments with other fiber sources, this may result in higher counts that don't necessarily indicate an asbestos risk. In such cases, additional analytical techniques such as Scanning Electron Microscopy (SEM) or Transmission Electron Microscopy (TEM) may be required.
Frequently Asked Questions
How long does air testing take?
The duration depends on the type of test. For clearance testing, air sampling typically takes at least 2 hours to achieve the minimum volume of 480 liters. Sample analysis takes approximately 1-2 hours. For background and reassurance monitoring, sampling may continue for 4-24 hours to obtain representative results.
What happens if air testing fails?
If clearance air monitoring results exceed 0.01 f/ml, the area requires further cleaning followed by another round of visual inspection and air testing. For leak testing, results above 0.01 f/ml indicate a potential breach in containment that must be immediately investigated and rectified. Work should be stopped until the issue is resolved.
Who can perform asbestos air testing?
In the UK, asbestos air testing should be conducted by competent persons, typically qualified analysts holding P403 (Asbestos Fiber Counting) and P404 (Air Sampling) certifications from the British Occupational Hygiene Society (BOHS). For clearance certification, the analysts must be accredited by UKAS to ISO 17025 standards.
Can I use DIY air testing kits?
DIY asbestos air testing kits are not recommended and have significant limitations. They cannot provide the accurate quantitative results needed for regulatory compliance, lack the calibration and quality control procedures used by professional laboratories, and may give a false sense of security. Professional testing by qualified analysts using calibrated equipment is the only reliable method.
Conclusion: The Importance of Professional Air Testing
Asbestos air testing is a critical component of asbestos management, providing objective data on airborne fiber concentrations to ensure safety and regulatory compliance. By understanding the different types of air testing and when each should be used, property owners and managers can make informed decisions about asbestos management.
Key points to remember:
- Different types of air testing serve specific purposes in the asbestos management process
- Professional testing by qualified, accredited analysts is essential for accurate and reliable results
- The clearance indicator of 0.01 f/ml is the benchmark for determining if an area is safe for reoccupation
- 4-stage clearance testing provides comprehensive verification that asbestos removal has been completed safely
- Regular air monitoring forms an important part of ongoing asbestos management in buildings containing asbestos materials
When planning any work involving asbestos or managing properties with asbestos-containing materials, always ensure that appropriate air testing is incorporated into your safety procedures and conducted by qualified professionals.
